Designed for general land clearing, the 14" and 16" Ranch Axe Tree Shears are the toughest, best engineered skid steer tree shears made!
SOLID STEEL SHEAR ARMS
The Maxx 14” & 16” Ranch Axe Tree Shear for skid steer loaders is the ideal tool for general land clearing. These shears are designed to handle trees up to 14 or 16 inches in diameter depending on model size. Maxx 14” Ranch Axe Tree Shears feature solid cast steel shearing arms that deliver 60% stronger performance compared to competing products, while Maxx 16” tree shears come equipped with fabricated A572 steel shearing arms that allow for larger diameter trees.
Maxx 14” Ranch Axe Tree Shears are available with two different styles of shear arms. Options include a standard arm design or an extended arm design. Standard shear arms are ideal for shearing hardwood such as mesquite, oak, osage orange (hedge), and locust, while open-end extended shear arms are suited for softwood species like cedar trees. The Maxx 16” Ranch Axe Tree Shear is available with standard shearing arms for tough and extreme applications.
Scroll to see more information »
Standard Steel Arm Model #
3458D9
3466D9
7180D2
Extended Arm Model #
3460D9
3468D9
N/A
Weight
1,630 lbs / 740 kg
1,820 lbs / 825 kg
1,925 lbs / 874 kg
Height (in.)
24″
50″
50″
Width at Shear Arms (in.)
66″
66″
66″
Overall Depth (in.)
46″ - Standard Arms
50” – Extended Arms
46″ - Standard Arms
50” – Extended Arms
48″
Shear Blade Material
3/4″ AR400 – bolt on replaceable milled knife
3/4″ AR400 – bolt on replaceable milled knife
3/4″ AR400 – bolt on replaceable milled knife
Shear
2
3.00"
5.00"
10.00"
Specifications are subject to change without notice*
